S-Link Swapp SW-HDMS44W U-HDMI 4K*4K@60Hz Matrix Switch
PRODUCT CODE
32469
To download the driver CLICK
| Explanation | HDMI Matrix Switch |
| Brand | S-link Swapp |
| Model | SW-HDMS44W |
| Color | Black |
| Input | 4 Pieces HDMI Type A Female Gold-Plated Connectors |
| Output | 4 Pieces HDMI Type A Female Gold-Plated Connectors |
| Connector | HDMI Type A Gold-Plated |
| Resolution | 480i@50Hz, 480p@60Hz, 576i@50Hz 576p@50Hz,720p@50/60Hz,1080i@50/60Hz,1080p@50/60Hz, 4Kx2K@25/30/60Hz |
| Data Transfer Rate | 18Gbps |
| Video Quality | 600MHz Band Width |
| HDCP Version | Copmpetible with HDCP 2.2 |
| HDMI Version | Copmpetible with HDMI 1.3 |
| Supported Audio Format | DTS-HD/Dolby-true HD/LPCM7.1/DTS/Dolby-AC3/DSD |
| Input/Output DDC Signal | 5Vp-p(TTL) |
| Input/Output TMDS Signal | 0.5~1.5Vp-p |
| Power source | DC 12V, 2A (Güç Adapter) |
| Power consumption | 15 Watt max. |
| Product Material | Metal, ABS |
| Connection | HDMI, RS232 (9 Pin for serial communication) |
| Usage | Plug and play |
| Operating temperature | 0 ~ 60 Degrees |
| Operating Humidity Range | 0%~90% Non-Condensed |
| Product Weight | 1734gr ±5gr |
| Product size | 28mm x 169mm x 249mm |
| Gross Weight | 2502gr ±5gr |
| Package Size | 108mm x 273mm x 482mm |
| Package Included | 1x Matrix Splitter + 1x power adapter+1x Remote Controller + 1x Montage apparatus+ User/Warranty |
| Warranty Time | 24 Months |
