S-Link Swapp SW-HDEX120PRO CAT 5/5E/6 120M HDMI Extender

S-Link Swapp SW-HDEX120PRO CAT 5/5E/6 120M HDMI Extender

PRODUCT CODE 32453
BARKODE 8680096083037
S-link Swapp

Share on Social Media

Was the product as you expected?

SPECIFICATIONS

You can list all the technical specifications of this product! Is this your product?

ExplanationHDMI Extender
BrandS-link Swapp
ModelSW-HDEX120PRO
ColorBlack
Communication distanceCAT5: 80m, CAT5E: 100m, CAT6: 120m
Resolution480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz 1080i@50/60Hz, 1080p@50/60Hz
Data Transmission MethodHDbitT
HDMI VersionCompatible with HDCP
Power sourceDC 5V, 1A (2 Pieces)
Power consumptionTX: 3.5 Watt, RX: 3 Watt
Product MaterialMetal, Plastic
ConnectionUTP/STP Cat5/Cat5e/Cat6, HDMI Type A Gold-Plated connectors
UsageTX: Connecting withTranceiver ex: PC, Video Rcorder, RX: Connecting with Receiver ex: Screen/Monitor
Operating temperature0 ~ 60 Degrees
Product WeightTX: 209gr ±5gr, RX: 192gr ±5gr
Product sizeTX: 23mm x 84mm x 130mm RX: 23mm x 84mm x 130mm
Gross Weight711gr ±5gr
Package Included1 pcs Receiver 1 pcs Transmitter + 2 Power Adapter+ 2 Pcs IR Cable + User Manual
Package Size81mm x 145mm x 200mm
Warranty Time24 Months
